GYXTW Single Mode Fiber Optic Cable Armored HDPE Sheath Aerial Duct Outdoor Optical Cable
GYXTW Single Mode Fiber Optic Cable Armored HDPE Sheath Aerial Duct Outdoor Optical Cable
GYXTW Single Mode Fiber Optic Cable Armored HDPE Sheath Aerial Duct Outdoor Optical Cable GYXTW Single Mode Fiber Optic Cable Armored HDPE Sheath Aerial Duct Outdoor Optical Cable GYXTW Single Mode Fiber Optic Cable Armored HDPE Sheath Aerial Duct Outdoor Optical Cable GYXTW Single Mode Fiber Optic Cable Armored HDPE Sheath Aerial Duct Outdoor Optical Cable
Hubungi sekarang

GYXTW Single Mode Fiber Optic Cable Armored HDPE Sheath Aerial Duct Outdoor Optical Cable

Kuantitas min Order : 1 km Harga : 60-200USD/KM
Kemasan rincian : Drum kayu Waktu pengiriman : 3-5 hari, itu tergantung pada jumlah Anda
Syarat-syarat pembayaran : L/C, D/A, T/T, Western Union, MoneyGram Menyediakan kemampuan : 60000 km/bulan
Tempat asal: Guangdong, Cina Nama merek: Jiqian/Customize/ OEM
Sertifikasi: CE/ISO9001/RoHS/FCC Nomor model: GYXTW-4/6/8/12B1

Informasi Detail
Jumlah serat: 2-24 inti Anggota kekuatan: untaian baja
Jaminan: 25 tahun Moq: 1 km
OEM: Ya Lapis baja: Ya
pabrik: Ya Konstruksi: Tabung longgar terdampar
Tidak ada inti: 24 pasang Tipe konektor: SC, LC, FC, ST, atau disesuaikan
Diameter luar: 10.5 ~ 18.8+_0.5mm Memperkuat inti: FRP
Kode Serat: Gyta53 Suhu: -20 derajat ~+70 derajat
Dame Luar Kabel: 8.9-10.2mm Sarung: HDPE/LSZH
Bahan baju besi: Pita aluminium bergelombang Baju zirah: Pita baja ganda
Bahan tabung longgar: PBT atau Jelly Jaket: PE, MDPE, LSZH, PVC
Modus peletakan: Saluran/udara Barang: Gyta
Jaket Luar Materail: PE Aplikasi: Komunikasi luar ruangan
Resistensi UV: Tersedia Tahan air: Ya
Struktur: Tabung longgar Serat Aramid: impor atau domestik
Menjangkau: 100m, 150m, 200m Serat per tabung: 12-144
Metode peletakan: Udara Warna kabel: Hitam
Model: PDLC-PDLC Instalasi: Aerial yang mendukung diri sendiri, udara, saluran
Menyoroti:

single mode armored fiber optic cable

,

outdoor HDPE fiber optic cable

,

aerial duct optical cable

Deskripsi Produk

Product Description

OEM Outdoor Duct Aerial GYXTW Armored Fiber Optic Cable Single Mode Multi Mode G652D 2 4 6 8 12 24 Core

Product Description :
GYXTW optical cable, also called central loose tube or light armored fiber optic cable, is one of the most widely used outdoor cables. It is typically available in 2 to 12 cores based on the fiber color code.

  • GY stands for outdoor cable design

  • X indicates the central loose tube structure

  • T means the tube is filled with water-blocking gel

  • W represents the polyethylene outer sheath with steel wire reinforcement

Thanks to its armored structure and durable HDPE jacket, GYXTW cable is ideal for aerial, duct, and direct-buried installation. This makes it a reliable choice for FTTx, long-distance communication, and backbone network projects.

GYXTW Single Mode Fiber Optic Cable Armored HDPE Sheath Aerial Duct Outdoor Optical Cable 0

Characteristics

  • Parallel steel wire strength members provide extra protection and stability.

  • Central loose tube with filling compound protects fibers and steel parts from moisture.

  • Corrugated tape armor delivers excellent crush resistance and durability.

  • Compact, lightweight construction for easy handling.

  • Simple and efficient installation.

Operating Temperature

  • From -40°C to +60°C, ensuring stable performance in harsh environments.

Applications

  • Designed for outdoor optical distribution networks.

  • Perfect for aerial, duct, and pipeline installation.

  • Suitable for long-haul transmission and LAN communication projects.

GYXTW Single Mode Fiber Optic Cable Armored HDPE Sheath Aerial Duct Outdoor Optical Cable 1
PRODUCT SPECIFICATIONS
Item
Parameters
Fiber Count
12
Colored coated fiber
Dimension
250µm±15µm
Color
Blue,Orange,Green,Brown,Gray,White,Red,Black,Yellow,Purple,Pink,Aqua
Loose tube
Dimension
2.2mm±0.1mm
Material
PBT
Color
nature
Filler
MATERIAL
none
color
none
Strength Member
Dimension
0.7mm±0.05mm
material
Phosphating steel wire
Armoured
Material
Plastic coated steel strip
Outer jacket
Material
PE
color
black
