48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable

Kuantitas min Order : 1 kilometer Kemasan rincian : drum kayu
Waktu pengiriman : 3-5 hari Syarat-syarat pembayaran : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Menyediakan kemampuan : 8000 kilometer per bulan
Tempat asal: Guangdong, Cina Nama merek: JQ/OEM/Customize
Sertifikasi: CE/ISO9001/RoHS/FCC Nomor model: GYTA33

Informasi Detail

Jenis kabel: GYTA33 Tempat Asal:: Guangzhou, Cina
Jumlah serat: 2-288core Tipe serat: Mode tunggal G652D atau sebagai permintaan Anda
Merek Serat: Yofc/fiberhome/corning/fujikura Jumlah konduktor: ≥ 10
Anggota kekuatan: Kawat Baja/Benang Kaca FRP Struktur: Tabung Longgar Terdampar
Lapis baja: Jaket ganda lapis baja ganda Bahan jaket: PE atau sebagai permintaan Anda
Struktur kabel: Pelindung Pita Aluminium Tabung Multi-Loose Aplikasi: Kapal selam di bawah laut
Suhu kerja: -40 ~+60 ℃ Tipe konektor: SC/FC/ST/LC
Jaminan: Lebih dari 25 tahun Sertifikasi: Sertifikasi ROHS, REACH, SGS, dan ISO
Bahan: serat optik Tabung longgar: PBT
Mode: Mode tunggal atau multi mode Sarung: HDPE/LSZH
Fitur: Pita aluminium bergelombang Jumlah serat: 8
Pabrikan: Ya Diameter Jaket: 12.8
Menggunakan: saluran/ udara/ bawah air/ penguburan langsung Metode instalasi: Udara
Warna Sarung Luar: Hitam
Menyoroti:

48 core steel wire armored fiber optic cable

,

direct burial underwater fiber optic cable

,

GYTA33 submarine fiber optic cable

Deskripsi Produk

The GYTA33 optical cable adopts a PBT loose tube design, where the optical fibers are housed and filled with thixotropic gel. At the center of the cable core lies a steel wire strength member, and for cables with higher core counts, a PE cushion layer is added. The loose tubes are stranded around the central strength member in an SZ pattern, with water-blocking compounds filling the interstices. The outer layer is reinforced with round steel wire armor and covered by a polyethylene sheath for enhanced protection.
48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable 0

The GYTA33 optical cable is designed for deployment in freshwater and shallow water environments. It can be laid directly without joints and is suitable for short-distance underwater communication.

Key Features:

  1. Strong resistance to mechanical stress and temperature variations.

  2. Steel wire armor provides high tensile strength.

  3. Longitudinal aluminum tape wrapping acts as an effective moisture barrier.

  4. Full cross-section water-blocking ensures protection against fresh or salt water intrusion.

  5. Outer jacket shields the cable from UV exposure.

  6. Flame-retardant sheath available upon request.

  7. Reliable operation when installed at depths up to 250 meters.

Product Specifications:
48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable 1
Package:
24 Core G652D GYTA33 Steel Armored Stranded Loose Tube Optical Fiber Cable
3km/Wooden Drum,Drum dimension 110*55*50cm,G.W 360.0kg.
48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable 2

FAQ

Q1: Are you a manufacturer or a trading company?
A1: We are a direct manufacturer.



Q2: Where is your factory located? How can I visit?
A2: Our factory is in Shenzhen, Guangdong Province. You can fly to Shenzhen or Guangzhou airport, and provide us with your flight number—we’ll arrange pickup.



Q3: Can I order samples?
A3: Of course! Sample orders are welcome for testing our quality and service.



Q4: What is the warranty period?
A4: All products come with a 12-month warranty.



Q5: What payment options do you support?
A5: We accept L/C, T/T, PayPal, Western Union, and MoneyGram.



Q6: Do you offer OEM/branding services?
A6: Yes, we provide professional OEM service. For bulk orders, custom logo printing is free of charge.
